DESIGNER OF THE MAJOR SIG® STUD WELDING PROCESS: TECHNOLOGICAL ADVANCEMENT

ASSEMBLY HAS NEVER GONE SO FAR IN TERMS OF QUALITY, RELIABILITY AND ECONOMY!

C2G, manufacturer of stud welding machines and weldable studs, offers universal applications for materials traditionally welded using MIG, TIG and Plasma, even those considered difficult. With the following characteristics: total bonding in all positions, no porosity, discreet and concave welding limiting the risk of notches and ‘roll neck’ effects.

SOUDAGE INNOVATION C2G also offers the first online shop exclusively dedicated to stud welding techniques and welding fasteners: eshop.c2g.fr
offering a wide range of welding equipment, welding studs and components using ARC (arc fusion forging), DEC (capacitor discharge) or SIG® (gas protected welding) processes accessible online and allowing users to easily and quickly obtain tools and consumables in the field of stud welding.

SUPPLIER OF WELDING RODS AND WELDING RODS

In addition to welding equipment designed and manufactured in France, C2G offers a wide range of weld studs: studs for concrete anchoring, studs for refractory materials, studs for insulation, zinc-plated steel clips, plastic clips, insulation needles, insulation nails.

Our threaded studs, sleeves, smooth studs and other welding components are available in two materials:

- Grade 4.8 steel with a carbon content suitable for welding, in accordance with DIN EN ISO 898-1.

- Stainless steel suitable for welding in A2-50 stainless steel and in accordance with DIN EN ISO 3506-1

The dimensions of the weld studs are listed in an online measurement table or in the catalogue. All standard stud sizes comply with DIN EN ISO 13918. We can supply special studs on request, subject to approval of the drawing.

Threads of welding studs: the threads are cold rolled (tolerance limit 6g). For studs with a special coating, the tolerance limit of 6h can be achieved. We can also supply studs with special threads on request.

A WIDE RANGE OF STUD BOLTS AND 4 PROCESSES FOR ALL APPLICATIONS

Weld studs Steel, for SIG, FF ARC, discharge or TC ARC welding processes:

Standard smooth stud, non-standard pine stud, non-standard bi-metal threaded weld stud with reduced base, non-standard threaded weld stud, non-standard stud with groove, non-standard smooth stud with flange, bimetal threaded studs, fully threaded welding studs with entry chamfers, smooth studs with entry chamfers, smooth welding studs, standardised partially threaded studs, smooth steel studs, zinc-plated bichromated threaded steel studs, etc.

Several sizes available.

Brass weld studs, for ARC TC or discharge welding processes

Stud with non-standard groove, standard threaded stud, standard smooth stud.

Aluminium weld studs, for ARC TC or discharge welding processes

Non-standard pine studs, non-standard grooved studs, standard threaded studs, standard smooth studs.

Stainless steel welding studs for SIG, FF ARC, discharge or TC ARC welding processes:

Standardised smooth studs, non-standardised pine studs, bi-metal threaded studs with reduced base, threaded studs, non-standardised fully threaded studs, standardised threaded studs, etc.

On request, copper or copper and nickel surface protection treatments are available, with a coating thickness in accordance with DIN EN ISO 4042.

C2G also supplies ceramics for weld studs, accessories for welding guns - mandrels, base holders, soles - single or double welding lugs, steel balls, threaded bushings.

A COMPLETE RANGE of services, ALL solutions FOR WELDING STUD

• Calibration of stud welding machines: cost control, improved productivity
• Training: from installation to adjustment and maintenance
• Rental of stud welding equipment: in the workshop or on site, all welding solutions
• Mechanisation of stud welding: optimised productivity and ergonomics with vibratory bowl feeding
• Subcontracting of stud welding in the workshop or on site
